NOARK Ex9C 3P 230V 1NO+1NC contactor
Warehouse stock
Accessories Accessories
-
6,05 € -
36,70 €
More info
The Ex9C line contactors are designed for industrial use. They meet the requirements of the IEC/EN 60947-4-1 standard. Four typical sizes of contactors are offered. Size 18 includes AC-3 usage category nominal currents of 9, 12, and 18 A. The second typical size - 38 is for nominal currents of 25, 32, and 38 A. Nominal currents of 40, 50, and 65 A are for size 65. Size 100 is for nominal currents of 80 and 100 A. Therefore, they can be used for switching on three-phase motors up to 45 kW power. The thermal current of these contactors is set up to 125 A. The devices can operate up to 690 V AC voltage. The coil control voltage can be chosen in the range of 24 - 415 V AC. Three-phase contactors with auxiliary contacts 11, or 22 installed. In the Ex9C contactors, one auxiliary front contact element (with two or four contacts) and one side contact element can be connected from the left and right. In addition, they can be combined with the Ex9R38 and Ex9R100 overcurrent relays.
Information on the manufacturer's website
Product features
| Nominal voltage | 230 V AC |
| Rated current | iki 100 A |
| Size | 18, 38, 65 ir 100 |
| Number of poles | 3P |
