SCHELINGER SPD01 1P 20kA T2 (C) Surge Arrester
- Combines Class T1+T2 protection for comprehensive surge defense
- Rated for 5kA 10/350 µs impulse current, ensuring robust performance
- 4-pole design suitable for three-phase systems
- High-quality components for reliable and long-lasting operation
- Easy installation and maintenance with clear status indicators
Warehouse stock
- Have a question?
- Phone: +370 37 205 802
- E-mail: parduotuve@elstila.lt
- Ask Question
More info
Information on the manufacturer's website
Product features
| Degree of protection | IP 20 |
| Mounting | ant DIN bėgelio |
| Type | T2 (C) class |
| Operating temperature | -40° C iki +70° C |
| Number of modules | 1 |
| Pulse/discharge current | 20 kA (8/20) / 40 kA (8/20) (maks.) |
| Voltage protection level | 1.5 kV |
| Maximum continuous voltage | 275 V AC |
